A map used in air navigation containing all or part of the following: topographic features, hazards and obstructions, navigation aids, navigation routes, designated airspace, and airports.
Aeronautical Chart
Designed to assist in the movement of ground traffic at locations with complex runway/taxiway configurations.
Airport Diagram
Designed to expedite clearance delivery and to facilitate transition between takeoff and en route operations.
Instrument Departure Procedure (DP)
Designed to expedite air traffic control arrival procedures and to facilitate transition between en route and instrument approach operations.
Standard Terminal Arrival (STAR)
Portray the aeronautical data which is required to execute an instrument approach to an airport.
Instrument Approach Procedure (IAP)
The height at which a decision must be made during an ILS or PAR instrument approach to either continue or to execute a missed approach.
